LNTV1616 is a high-lumen, high performance flexible LED fixture designed as a neon replacement and is also useful in a wide variety of indoor or outdoor applications where a smooth surface or continuous line of light is desired. The LNTV1616 is a flexible strip light that can bend around contours and tight curves without being damaged. It allows for easy installation with its factory sealed terminators and self locking male and female barrel connectors. Fully encapsulated UV protected wet location rated.
| INPUT VOLTAGE | 24V DC Constant Voltage |
| POWER CONSUMPTION | 4W per Ft. |
| LUMEN OUTPUT | 279Lm/Ft. |
| LED CHIP | NICHIA |
| CRI | 88+ |
| COLOR TEMPERATURE | 30K/40K/60K |
| DIMMING/CONTROL | MLV, ELV, 0-10 and TRIAC |
| MAXIMUM RUN LENGTH | 32 Ft. |
| CUTTABLE | Every 50mm (2.19 in) |
| STORAGE TEMPERATURE | -40°F (-40°C) to 176°F (80°C) |
| OPERATING TEMPERATURE | -40°F (-20°C) to 113°F (45°C) |
| BEAM ANGLE | 160 |
| HUMIDITY | 0-95% Non Condensing |
| IP RATING | IP67/IP68 |
| CERTIFICATIONS | UL Listed |
| LUMEN MAINTENANCE | 50,000 Hrs |
High color consistency
Smooth illumination
Multiple CCT options available
Continuous run length up to 32 Ft.
Bottom, Side and End feed options
UL Listed (US and Canada)
