SPIR3 – 3 in 1 SPI LED Controller (2.4GHz)

The SPIR3 is a 3 in 1 SPI LED controller with 2.4GHz wireless transmission, supporting single color, RGB, and RGBW SPI output with up to 20 dynamic modes.

The SPIR3 is a 3 in 1 SPI LED controller with 2.4GHz wireless transmission technology, designed for pixel LED strips.

It offers stable signal transmission, high antiinterference performance, 20 dynamic modes, ON/OFF time and color setting, and support for single color, RGB, and RGBW output modes.

3 in 1 = Single color + RGB + RGBW SPI controller
Pixel Dots: Single color (2048), RGB (1536), RGBW (1024)
Output Signal: SPI (TTL) 800Kbps
Setting color and length
Setting ON/OFF time and color
Selecting single color, RGB or RGBW output mode via "SET" button
Push ON/OFF and changing dynamic mode
Total 20 dynamic modes and support editing color of them
Have DND function, usually used for power failure area to save power

3 in 1 2.4GHz SPI(TTL) Max 10A IP20 5 Years

SPIR3 – 3 in 1 SPI LED Controller (2.4GHz)

PRODUCT NAME	3 in 1 SPI LED Controller (2.4GHz)
MODEL NO.	SPIR3
INPUT VOLTAGE	DC5V~24V
OUTPUT CURRENT	Max 10A
OUTPUT POWER	50240W
OUTPUT TYPE	Constant Voltage
OUTPUT SIGNAL	SPI(TTL) 800Kbps
CONTROL DISTANCE	30m
PIXEL DOTS	Single color (2048), RGB (1536), RGBW (1024)
CONTROL SIGNAL	2.4GHz RF
IP RATE	IP20
WORKING TEMPERATURE	10~40°C
DIMMING GRAYSCALE	4096 Levels
DIMMING RANGE	0.1%100%
DIMMING CURVE	Logarithmic
CERTIFICATION	CE, EMC, LVD, RED
WARRANTY	5 Years

3 in 1 = Single color + RGB + RGBW SPI controller
Pixel Dots: Single color (2048), RGB (1536), RGBW (1024)
Output Signal: SPI (TTL) 800Kbps
Setting color and length
Setting ON/OFF time and color
Selecting single color, RGB or RGBW output mode via "SET" button
Push ON/OFF and changing dynamic mode
Total 20 dynamic modes and support editing color of them
Have DND function, usually used for power failure area to save power
