Home / Products / HW5 – 5 in 1 LED Controller (WiFi+2.4G)

HW5 – 5 in 1 LED Controller (WiFi+2.4G)

The HW5 is a 5 in 1 LED controller with WiFi + 2.4G control, Tuya Smart app support, music rhythm, voice assistant support, and a total output of up to 30A.

The HW5 is a 5 in 1 LED controller with WiFi + 2.4G connectivity and a maximum total output of 30A.

It supports the Tuya Smart app, music rhythm, thirdparty voice control, push dimming, and switching between single color, dual white, RGB, RGBW, and RGB+CCT output modes.

  • Support "Tuya Smart" app control
  • Support music rhythm
  • Support third party voice control (Alexa, Google Assistant)
  • 2.4G RF remote controllable
  • 16 millions of colors to choose, color temperature adjustable, brightness and saturation controllable
  • Support PUSH dimming
  • Switching 5 output mode via one button (Single color / Dual white / RGB / RGBW / RGB+CCT)
5 in 1 WiFi+2.4G Max 30A DC12~48V 30m Tuya Smart
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
HW5 – 5 in 1 LED Controller (WiFi+2.4G)
PRODUCT NAME 5 in 1 LED Controller (WiFi+2.4G)
MODEL NO. HW5
INPUT VOLTAGE DC12~48V
OUTPUT 15A/Channel
TOTAL OUTPUT Max 30A
COMMUNICATION PROTOCOL WiFi + 2.4GHz
CONTROL DISTANCE 30m
WORKING TEMPERATURE 10~40°C
WIFI STANDARD IEEE 802.11b/g/n 2.4GHz
BLUETOOTH PROTOCOL Bluetooth 4.2 (low power consumption)
  • Support "Tuya Smart" app control
  • Support music rhythm
  • Support third party voice control (Alexa, Google Assistant)
  • 2.4G RF remote controllable
  • 16 millions of colors to choose, color temperature adjustable, brightness and saturation controllable
  • Support PUSH dimming
  • Switching 5 output mode via one button (Single color / Dual white / RGB / RGBW / RGB+CCT)
