TDJ SERIES indoor/outdoor drivers are highly efficient and stable with smooth dimming capability compatible with most TRIAC, ELV, MLV, reverse and forward phase dimmers, and on/off switches. These drivers are derated, allowing them to be loaded to maximum wattage capacity.
| INPUT VOLTAGE | 120VAC |
| OUTPUT TYPE | Constant voltage |
| OPERATING VOLTAGE | 24V DC |
| RATED POWER | 96W |
| DIMMING FUNCTION | Electronic Transformer Triac / ELV / MLV dimming |
| DIMMING RANGE | 0100% |
| THD | THD<20%@120V Max. load |
| WATERPROOF PERFORMANCE | For dry and damp locations | Wet location |
| SMALL SIZE | 126.4x80x40.4 mm / 4.97×3.15×1.59 inch |
| LOADING | Operates flawlessly at 20%100% load |
| COMPATIBILITY | Compatible with popular dimmers including Lutron CL / Diva series |
| PROTECTION | Short circuit / over load |
| WARRANTY | 5 years warranty |
